HARD PARTS

Quality replacement Regulator / Rectifiers

Please Note:

1. All electrical components must be fitted by a qualified technician.
2. Before fitting electrical components ensure the root cause of the original failure has been addressed.
3. The absence of either of points 1 or 2 above, will void any warranty.

• Pack of 100
• Black

Carburetor repair kits
• Kits include all of the necessary components to repair a carburetor. ATV models with two carburetors include components to repair two carburetors.
• Kit includes necessary all O-rings, gaskets, jets, needle, mixture screw, float bowl screws, float valve needle and seat. (Needle jet and other pressed in jets are not included in kit.)
• OEM jet sizes are included in the kit. NBR rubber material is used on all O-rings and rubber gaskets NBR has excellent resistance to the ethanol used in today’s fuels.
• Applications that use paper float bowl gaskets are upgraded to High Performance Interface Gasket material.
• Components included in the kits are based off of US models and discretion must be used when attempting to install the kit on a non US model.
• Off road use only.

If your old parts are defective, RMStator offers replacement parts of high quality at a fraction of the cost of genuine parts.

• Direct replacement to your original unit.
• The Quality exceeds the OEM equipment.
• Connectors and 12 inches of wires included.
• To use with 7 mm diameter plug wires.
• 1 Spark plug cap included.
• All shipped products are tested.

Dimensions:

• Length: 110 mm
• External diameter: 26 mm
• Internal diameter (Spark plug): 9.5 mm
• Internal diameter (Coil wire) : 6.5 mm

All the bearings and seal required to refit a wheel in one convenient package.

Features:

• Premium high-speed bearings feature low drag.
• Double lip seals on both sides to provide superior exclusion of water and dirt
• Improved grease retention.

Direct replacement to your original unit.

• Plug-and-play, direct fit, easy installation.
• Made with the highest grade of lamination materials.
• Features the highest grade of copper winding, resistant to 200 degrees Celsius.
• Includes a pick up pulsar coil.
• Comes with connectors.
• Includes a rubber grommet.
• Back plate is included.
• All products are tested before shipping.

We have even included the opposite connector (main harness side) as we know these are often melted / corroded / defective and a major cause of repetitive electrical issues.

Dimensions:

• Interior diameter: 27 mm
• Exterior diameter: 109 mm
• Thickness: 32.6 mm
• Length of wires (stator to grommet): 135 mm
• Length of wires (grommet to plug): 410 mm
• Length of pickup coil's wire to grommet: 135 mm

Other Specifications:

• Number of wires: 6
• Number of plugs: 1
• Number of pins: 6
• Number of poles: 4
• Wire to wire resistance:
  • Pickup: White/Blue to White/Red = 293 ohms ±20%
  • Source: Green/White to Black/Red = 858 ohms ±20%
  • Source: Black to Green/Blue = 53 ohms ±20%

GOLDfren began manufacturing sintered disc brake pads for a wide range of off-road and road motorcycles in 1991, nearly three decades on from their first motorcycle brake pads GOLDfren has become one of the largest aftermarket manufacturers in the motorcycle brake disc pad industry. Their development of next-generation products has kept them at the technological forefront of Sintered Friction Braking providing you with confidence in the performance, durability and reliability of your brakes.

K5 Series:

The K5 sintered compound is optimal for off-road motorcycles and ATVs. It is recommended for riders who demand great off-road stopping power and brake pad durability when riding on tough off-road terrains. The K5 series is designed for low abrasive interaction with the rotor, long life and self-cleaning capabilities necessary in off-road riding conditions. Friction materials contain metal-ceramic with a sophisticated bronze-graphite and full-metal mixture formulation with fine friction particles to achieve optimal friction properties.

Features:

• High static friction coefficient
• Good abrasive resistance
• Self-cleaning capability
• Low abrasive interaction with the brake rotor material
• Up to 3 times longer operational life compared to organic and Kevlar composite materials

Application:

• Developed specifically for off-road motorcycles & ATVs
• Can be used on both front and rear brakes
• Could be used on the rear brake of road racing motorcycles

Operating Parameters:

• Specific pressure: 2.0 Mpa
• Sliding velocity: 20 m/s
• Constant maximum temp: 500°C
• Short time maximum temp: 750°C
• Counter-surfaces: steel disks

What is a sintered brake pad?

GOLDfren only manufacturers sintered brake pads that contain metal-ceramic and ceramic-carbon friction materials, these materials allow for less brake dust and a quieter braking experience. Sintered brake pads are made by fusing together metallic particles under high temperature and pressure which enhances friction properties and pad life, resulting in longer life and stronger braking. Sintered brake pads experience no brake fade when operating at high temperatures and in wet conditions. They also last up to 5 times longer than organic pads and provide additional braking strength. All materials used are environmentally friendly and do not contain any lead, asbestos, fibreglass or formaldehyde.

Reminder: one set of brake pads services one brake disc, if you are servicing multiple discs you will need multiple sets of brake pads.

All the bearings and seal required to refit a wheel in one convenient package.

Features:

• Premium high-speed bearings feature low drag.
• Double lip seals on both sides to provide superior exclusion of water and dirt
• Improved grease retention.

GOLDfren began manufacturing sintered disc brake pads for a wide range of off-road and road motorcycles in 1991, nearly three decades on from their first motorcycle brake pads GOLDfren has become one of the largest aftermarket manufacturers in the motorcycle brake disc pad industry. Their development of next-generation products has kept them at the technological forefront of Sintered Friction Braking providing you with confidence in the performance, durability and reliability of your brakes.

S3 Series:

The S3 sintered compound is optimal in dry and wet conditions for road & off-road motorcycles. For the road application, S3 pads are suitable for both the front and rear brake while on off-road applications the S3 is only recommended for the front brake. The S3 series is designed for low abrasive interaction with the rotor and quieter braking due to the ceramic composite material. It has an HH friction rating and performs better at higher temperatures than the AD compound. Friction materials contain metal-ceramic with a bronze-graphite and non-metallic friction additives are spread evenly on the base fine bronze body to achieve optimal friction properties.

Features:

• Very high static friction coefficient
• Minimal difference between wet and dry braking performance
• Good abrasive resistance
• Low abrasive interaction with the brake rotor material
• Longer life compared to organic and Kevlar composite materials

Application:

• For riders who demand a bit more than average from their bikes
• Recommended on both front and rear brakes (road application)
• Can also be used on the front brakes of off-road bikes and ATVs
• Works well on both dry and wet conditions

Operating Parameters:

• Specific pressure: 3.0 Mpa
• Sliding speed: 45 m/s
• Constant maximum temp: 450°C
• Short time maximum temp: 800°C
• Counter-surfaces: steel disks

What is a sintered brake pad?

GOLDfren only manufacturers sintered brake pads that contain metal-ceramic and ceramic-carbon friction materials, these materials allow for less brake dust and a quieter braking experience. Sintered brake pads are made by fusing together metallic particles under high temperature and pressure which enhances friction properties and pad life, resulting in longer life and stronger braking. Sintered brake pads experience no brake fade when operating at high temperatures and in wet conditions. They also last up to 5 times longer than organic pads and provide additional braking strength. All materials used are environmentally friendly and do not contain any lead, asbestos, fibreglass or formaldehyde.

Reminder: one set of brake pads services one brake disc, if you are servicing multiple discs you will need multiple sets of brake pads.

Kit contains all of the components required to rebuild the shock bearing assembly properly.

Features:

• Needle bearing shafts are made with SCM415/42 bearing steel that has been hardened and precision ground.
• All metal bushings are case-hardened and plated to prevent wear and corrosion.
• POM composite washer bearings replace thru needle washers and increase service life and superb resistance to water and dirt.

Quantum replacement fuel pumps, modules, assemblies, and kit components are designed to meet or exceed OEM specifications and feature upgrades that improve on the OEM design. Upgraded polymers, brushes, and commutators ensure long life and durability in multiple fuel blends.

Features:

• OEM or better performance.
• Drop-in replacement.
• Gradient density fuel strainer for superior contaminant filtration.
• Compatible with modern ethanol-infused pump gasoline.

All Balls manufactures a wide range of high-quality products to keep you out there on your Motorbike, ATV or UTV. All Balls Sintered Brake Pads are engineered to be extremely durable and dependable, while withstanding high-speed environments.

K&N's high-flow air filters are available as a replacement for your stock motorcycle air filter element. They are custom-engineered to fit your specific application and are designed to provide low restriction and increased performance while providing excellent engine protection for your motorcycle.

Features:

• Designed to provide increased horsepower and torque.
• Pleated media provides a large filtration area, offering long service intervals.
• Multiple layers of woven cotton gauze media offer excellent filtration.
• Application-specific base seal and sealing bead.
• Made in the USA for over 40 years.
• Washable and reusable, pre-oiled and ready to ride!

Specifications:

• Heigh t: 0.813in (21mm)
• Washable: Yes
• Filter Material: Cotton Gauze
• Outside Length: 10in (254mm)
• Outside Width: 6.063in (154mm)
• Filter Re-Oiling Amount: 0.86oz (25ml)

Produced in the U.S.A. with the latest materials and technology in gasket production to Vertex specifications. Vertex gaskets ensure long-lasting performance and leak prevention for your rebuild needs.

• Ignition cover gasket
• Designed to fit O.E.M. cover

Quantum replacement fuel pumps are designed to meet or exceed OEM specifications, and feature upgrades that improve on the OEM design. Upgraded polymers, brushes, and commutators ensure long life and durability in multiple fuel blends.

Features & Benefits

• OEM or better performance
• Polished corrosion-resistant case to help minimize seizing during non-operation
• Specifically designed for quiet operation
• Drop-in replacement
• Patented check valve technology
• Compatible with modern ethanol-infused pump gasoline

Quality replacement components to rebuild one fuel tap. Improves service life and resistance to water and dirt.

Includes:

• Face screws
• Face gasket
• Wave washer
• Tank bolts
• Tank gasket
• O-rings

These brake disks are made of 420 stainless steel, providing excellent corrosion resistance.

• Hardened to 36HRC for excellent braking performance and durability
• Precision ground surfaces
• Laser engraved with part number and minimum thickness specification

K&N's Universal Air Filters are designed and manufactured for a wide variety of applications including racing vehicles, radio-controlled cars, generators, snowmobiles, tractors, and other applications. Regardless of the angle or offset diameter of the air intake, there is probably a K&N Universal air filter for your equipment. All filters are constructed with ultra-strong moulded pliable rubber flanges which absorb vibration and allow for secure attachment and can also be stretched for up to 1/16 of an inch (1.5mm) to fit in-between sizes. K&N universal air filters are washable and reusable.

Features:

• Designed to increase horsepower and acceleration.
• Hundreds of sizes and shapes for most applications.
• High airflow with excellent filtration.
• Clamp-on washable and reusable air filter.
• Malleable flanges.

Specifications:

• Filter Material: Cotton Gauze
• Base Outside Diameter: 67mm
• Top Outside Diameter: 51mm
• Height: 76mm
• Flange Inside Diameter: 40mm
• Flange Length: 16mm
• Flange Type: Centred

NOTE: This complete Vertex Gasket Set contains all parts as pictured.

Produced in the U.S.A. with the latest materials and technology in gasket production to Vertex specifications. Vertex gaskets ensure long-lasting performance and leak prevention for your rebuild needs. Vertex's replacement gaskets and seals are available as top-end kits, complete engine kits, or as an oil seal kit.

• One kit containing all of the gaskets, O-rings, and valve seals necessary to rebuild the entire engine and transmission.
• Includes transmission seals.

Produced in the U.S.A. with the latest materials and technology in seal production to Vertex specifications. Vertex seals ensure long-lasting performance and leak prevention for your rebuild needs.

Features:

• OEM replacement mechanical water pump seal.
• High-quality seal face material seals better and lasts longer.
• Corrosion and chemical-resistant materials keep your engine clean, safe and cool.
• Meets or exceeds OEM quality.

Plug-and-play, aftermarket replacement CDI box for Yamaha outboard motors from RM Stator. Refer to fitment guide for models.

Dimensions:

• Height: 40 mm
• Length: 54 mm
• Width: 35 mm

Other specifications:

• Number of plugs: 7
• Number of pins: 7
• Fixation holes center to center: 75 mm
• Please note that: The only real way to test your CDI box is to swap it out with another known good unit from the same year/make/model. Because of this, we recommend that you rule everything else out before replacing the CDI box.

Details:

• RM Stator's PeakRPM technology provides a more aggressive timing curve for increased throttle response
• Ride at full throttle with their application-specific CDI box that raises the rev limiter by 1000 RPM
• Enjoy fast and easy installation with their plug and play design and included dielectric connector grease
• OEM-grade electronic components and printed circuit boards for long-term reliability and performance
• 90% of ignition issues are caused by a faulty stator. Fully test ignition components before buying

A quality pair of fork oil and dust seals from All Balls Racing.

Features:

• Dyno tested to last 3 to 4 times longer than OEM seals.
• Directional ribs outside of the seal allow easy installation.
• Dual-sealing lips guarantee oil stays in and dirt stays out.

Available individually in left-hand and right-hand thread or sold in pairs one L/H and one R/H thread.

Includes components necessary to complete a piston (top end) rebuild. Competitive pricing, made to meet and exceed OEM quality and designed as a direct OEM replacement.

Features:

• Designed for OEM replacement.
• Made from high-quality materials.
• Meet or exceed OEM specifications.
• Competitive pricing.

Hot Start Plunger Kit including all required rebuild parts.
For HON CRF150R/250R/450R,KX250,RMXZ250

P SERIES - Street Bikes

Premier's most successful general use material, our P series pads, are a tough Kevlar based organic material giving superb brake effect on all sportbikes and cruisers. This material is preselected by the catalogue when you order P prefix disc pads.

P SERIES - Off-Road

Part numbers relating to off-road machines are supplied in carbon graphite compound for medium durability, good brake effect and minimum heat generation.

The most convenient one-stop-shop for maintaining your motorcycle. Kits include front brake pads/shoes, rear brake pads/shoes, an air filter with 1L of filter oil and an oil filter where applicable.

This kit includes:

GF041S3 - BRAKE PADS GOLDFREN GF041-S3
GF346K5 - BRAKE PADS GOLDFREN GF346-K5
PUTAFBE8139 - AIR FILTER BETA ENDURO 250/400/450/525 RR 2005-2012
PTAAFO1L - PUTOLINE ACTION AIR FILTER OIL 1LT (70005) *12
MFO631 - MOTO-FILTER OIL FILTER (HF631) SINGLE
